Brand Name:
Huawei
Model Number:
S6730-H48X6C Bundle
Document:
| Model | S6730-H48X6C |
|---|---|
| Part Number | Bundle version: 02353FWL/02353FWL-003/02353FWL-005/02353FWL-006 Without bundle: 02352FSF/02352FSF-003/02352FSF-007/02352FSF-009/02352FSF-011 |
| Memory | 4 GB |
| Flash Memory | 2 GB total (view available size using display version command) |
| PoE Support | Not supported |
| Weight with Packaging | 9.2 kg (20.28 lb) |
| Weight without Packaging | 5.84 kg (12.87 lb) |
| Dimensions (W x D x H) | 442 mm x 420 mm x 43.6 mm |
| Part Number | 02353FWL | 02353FWL-003 | 02353FWL-005 | 02353FWL-006 |
|---|---|---|---|---|
| Maximum Input Current | Depends on pluggable power modules | Depends on pluggable power modules | Related to pluggable power module | Related to pluggable power module |
| Operating Temperature | -5°C to +45°C (23°F to 113°F) at 0-1800m altitude | -5°C to +45°C (23°F to 113°F) at 0-1800m altitude | -5°C to +45°C (23°F to 113°F) at 0-1800m altitude | -5°C to +45°C (23°F to 113°F) at 0-1800m altitude |
| Model | Description |
|---|---|
| eSFP-GE-SX-MM850 | Optical Transceiver, eSFP, GE, Multi-mode Module (850nm, 0.55km, LC) |
| SFP-GE-LX-SM1310 | Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 10km, LC) |
| eSFP-GE-ZX100-SM1550 | Optical Transceiver, eSFP, GE, Single-mode Module (1550nm, 100km, LC) |
| SFP-GE-LX-SM1310-BIDI | Optical Transceiver, eSFP, GE, BIDI Single-mode Module (TX1310/RX1490, 10km, LC) |
| SFP-GE-LX-SM1490-BIDI | Optical Transceiver, eSFP, GE, BIDI Single-mode Module (TX1490/RX1310, 10km, LC) |
| LE2MGSC40DE0 | Optical Transceiver, eSFP, GE, BIDI Single-mode Module (TX1310/RX1490, 40km, LC) |
| LE2MGSC40ED0 | Optical Transceiver, eSFP, GE, BIDI Single-mode Module (TX1490/RX1310, 40km, LC) |
| SFP-GE-ZBXD1 | Optical Transceiver, eSFP, GE, BIDI Single-mode Module (1570nm(Tx)/1490nm(Rx), 80km, LC) |
| SFP-GE-ZBXU1 | Optical Transceiver, eSFP, GE, BiDi Single-mode Module (1490nm(Tx)/1570nm(Rx), 80km, LC) |
| SFP-GE-BXU1-SC | 1000Base, BIDI Optical Transceiver, SFP, GE, Single-mode Module (TX1490nm/RX1310nm, 10km, SC) |
| CWDM-SFPGE-1551 | CWDM Optical Transceiver, eSFP, 2.5G, Single-mode Module (1551nm, 80km, LC) |
| CWDM-SFPGE-1571 | CWDM Optical Transceiver, eSFP, 2.5G, Single-mode Module (1571nm, 80km, LC) |
| CWDM-SFPGE-1591 | CWDM Optical Transceiver, eSFP, 2.5G, Single-mode Module (1591nm, 80km, LC) |
| DWDM-SFPGE-1560-61 | DWDM Optical Transceiver, eSFP, 2.5G, Single-mode Module (1560.61nm, 120km, LC) |
| SFP-1000BaseT | Electrical Transceiver, SFP, GE, Electrical Interface Module (100m, RJ45) |
| SFP-10G-USR | 10GBase-USR Optical Transceiver, SFP+, 10G, Multi-mode Module (850nm, 0.1km, LC) |
| OMXD30000 | Optical Transceiver, SFP+, 10G, Multi-mode Module (850nm, 0.3km, LC) |
| SFP-10G-iLR | Optical Transceiver, SFP+, 10G, Single-mode Module (1310nm, 1.4km, LC) |
| OSX010000 | Optical Transceiver, SFP+, 10G, Single-mode Module (1310nm, 10km, LC) |
| OSX040N01 | Optical Transceiver, SFP+, 10G, Single-mode Module (1550nm, 40km, LC) |
| SFP-10G-ER-1310 | Optical Transceiver, SFP+, 10G, Single-mode Module (1310nm, 40km, LC) |
| SFP-10G-ZR | 10GBase-ZR Optical Transceiver, SFP+, 10G, Single-mode Module (1550nm, 80km, LC) |
| SFP-10G-ZCW1551 | Optical Transceiver, SFP+, 10G, Single-mode Module (CWDM, 1551nm, 70km, LC) |
| SFP-10G-ZCW1571 | Optical Transceiver, SFP+, 10G, Single-mode Module (CWDM, 1571nm, 70km, LC) |
| SFP-10G-ZCW1591 | Optical Transceiver, SFP+, 10G, Single-mode Module (CWDM, 1591nm, 70km, LC) |
| SFP-10G-ZCW1611 | Optical Transceiver, SFP+, 10G, Single-mode Module (CWDM, 1611nm, 70km, LC) |
| QSFP-40G-SR4 | 40GBase-SR4 Optical Transceiver, QSFP+, 40G, Multi-mode (850nm, 0.15km, MPO) |
| QSFP-40G-iSR4 | 40GBase-iSR4 Optical Transceiver, QSFP+, 40G, Multi-mode (850nm, 0.15km, MPO) (Connect to four SFP+ Optical Transceiver) |
| QSFP-40G-eSR4 | 40GBase-eSR4 Optical Transceiver, QSFP+, 40G, Multi-mode (850nm, 0.3km, MPO) (Connect to four SFP+ Optical Transceiver) |
| Feature | S6730-H24X6C | S6730-H48X6C |
|---|---|---|
| Fixed Ports | 24 x 10 Gig SFP+, 6 x 40/100 Gig QSFP28 | 48 x 10 Gig SFP+, 6 x 40/100 Gig QSFP28 |
| Dimensions (W x D x H) | 442 mm x 420 mm x 43.6 mm | 442 mm x 420 mm x 43.6 mm |
| Chassis Height (U) | 1U | 1U |
| Input Voltage | AC: 100-240V AC, 50/60 Hz DC: -48V to -60V DC |
AC: 100-240V AC, 50/60 Hz DC: -48V to -60V DC |
| Input Current | AC 600W: Max 8A DC 1000W: Max 30A |
AC 600W: Max 8A DC 1000W: Max 30A |
| Maximum Power Consumption | 231W | 274W |
| Minimum Power Consumption | 97W | 97W |
