Brand Name:
Huawei
Model Number:
S5730-44C-PWH-HI
Document:
| Model | S5730-44C-PWH-HI |
|---|---|
| Part Number | 02351LKB |
| Memory | 2 GB |
| Flash memory | 1 GB in total (view available size via display version command) |
| PoE | Supported |
| Weight (including package) | 8.5 kg (18.74 lb) |
| Dimensions (H × W × D) |
Basic dimensions: 44.4 mm × 442.0 mm × 424.7 mm (1.75 in. × 17.4 in. × 16.72 in.) Maximum dimensions: 44.4 mm × 442.0 mm × 451.8 mm (1.75 in. × 17.4 in. × 17.79 in.) With 1150W power modules: Total depth becomes 541.1 mm (21.3 in.) |
| ① | Twenty-four PoE++ 10/100/1000BASE-T ports |
|---|---|
| ② | Four 10GE SFP+ ports |
| ③ | One ETH management port |
| ④ | One PNP button |
| ⑤ | One console port |
| ⑥ | One USB port |
| ⑦ | Ground screw |
| ⑧ | ESN label |
| ⑨ | SSD card slot |
| ⑩ | Rear card slot |
| ⑪ | Fan slot |
| ⑫ | Power module slot 2 |
| ⑬ | Power module slot 1 |
| Model | Description |
|---|---|
| eSFP-GE-SX-MM850 | Optical Transceiver, eSFP, GE, Multi-mode Module (850nm,0.5km, LC) |
| SFP-GE-LX-SM1310 | Optical Transceiver, eSFP, GE, Single-mode Module (1310nm,10km, LC) |
| S-SFP-GE-LH40-SM1310 | Optical Transceiver, eSFP, GE, Single-mode Module (1310nm,40km, LC) |
| S-SFP-GE-LH40-SM1550 | Optical Transceiver, eSFP, GE, Single-mode Module (1550nm,40km, LC) |
| S-SFP-GE-LH80-SM1550 | Optical Transceiver, eSFP, GE, Single-mode Module (1550nm,80km, LC) |
| eSFP-GE-ZX100-SM1550 | eSFP, GE, Single-mode Module (1550nm,100km, LC) |
| SFP-1000BaseT | 1000BASE-T (RJ45) SFP Electrical Module, Auto Negotiate,100m |
| Item | S5730-36C-HI | S5730-36C-PWH-HI | S5730-44C-HI | S5730-44C-PWH-HI |
|---|---|---|---|---|
| Fixed Ports | 24 x 10/100/1,000 Base-T ports, 4 x 10 GE SFP+ ports | 24 x 10/100/1,000 Base-T (PoE++) ports, 4 x 10 GE SFP+ ports | 24 x 10/100/1,000 Base-T ports, 4 x 10 GE SFP+ ports | 24 x 10/100/1,000 Base-T (PoE++) ports, 4 x 10 GE SFP+ ports |
| Dimensions (W × D × H) | 442 mm × 420 mm × 44.4 mm | 442 mm × 420 mm × 44.4 mm | 442 mm × 420 mm × 44.4 mm | 442 mm × 420 mm × 44.4 mm |
| Extended Slots | One extended slot | One extended slot | Two extended slots | Two extended slots |
| Input Voltage | AC: 100-240V, 50/60 Hz DC: -48V to -60V |
AC: 100-240V, 50/60 Hz DC: -48V to -60V |
AC: 100-240V, 50/60 Hz DC: -48V to -60V |
AC: 100-240V, 50/60 Hz DC: -48V to -60V |
