Brand Name:
Huawei
Model Number:
6776-58TI
Document:
| Model | 6776-58TI |
|---|---|
| Part Number | 50087136 |
| Dimensions (H x W x D) | 61 mm x 220 mm x 220 mm |
| Power Input | DC: 43.2 V to 57.6 V PoE power supply: 802.3bt/at compliant (dual PoE inputs for hot backup) |
| Maximum Number of Users | 1800 Actual user count varies according to environment |
| Operating Temperature | -10°C to +50°C |
| Antenna Type | Built-in smart antennas |
| MIMO: Spatial Streams | 2.4 GHz: 2x2:2, 5 GHz: 4x4:4, 6 GHz: 2x2:2 or 2.4 GHz: 4x4:4, 5 GHz: 4x4:4 |
| Radio Protocols | 802.11a/b/g/n/ac/ac wave2/ax/be |
| Maximum Rate | 7.89 Gbit/s |
| Model | 6776-58TI |
|---|---|
| Part Number | 50087136 |
| Dimensions (H x W x D) | 61 mm x 220 mm x 220 mm |
| Weight | 1.47 kg |
| Port Type | 1 x 100M/1000M/2.5GE/5GE (RJ-45) 1 x 10M/100M/1000M (RJ-45) 1 x USB port The 5GE(RJ-45) and GE(RJ-45) support PoE input |
| IoT Capabilities |
|
| IoT Expansion | Two built-in IoT slots (PCIe) supporting ZigBee, RFID, and Thread Bluetooth function unavailable when two serial port IoT cards are used simultaneously |
| Bluetooth | BLE 5.4 |
| LED Indicator | Indicates power-on, startup, running, alarm, and fault states |
| Power Input | DC: 43.2 V to 57.6 V PoE power supply: 802.3bt/at compliant (dual PoE inputs for hot backup) |
| Maximum Power Consumption | 23.9 W (excluding USB and IoT cards) |
| Operating Temperature | -10°C to +50°C |
| Storage Temperature | -40°C to +70°C |
| Operating Humidity | 5% to 95% (non-condensing) |
| Altitude | -60 m to +5000 m |
| Atmospheric Pressure | 53 kPa to 106 kPa |
| Antenna Type | Built-in smart antennas |
| Antenna Gain | 2.4 GHz: 4 dBi 5 GHz: 5 dBi 6 GHz: 5 dBi |
| Maximum SSIDs per Radio | 16 |
| Maximum Transmit Power |
Mode 1: 2.4 GHz (2x2): 23 dBm (combined power) 5 GHz (4x4): 26 dBm (combined power) 6 GHz (2x2): 23 dBm (combined power) Mode 2: 2.4 GHz (4x4): 26 dBm (combined power) 5 GHz (4x4): 26 dBm (combined power) |
| Frequency Bands |
2.400 to 2.4835 GHz ISM 5.150 to 5.250 GHz U-NII-1 5.250 to 5.350 GHz U-NII-2A 5.470 to 5.725 GHz U-NII-2C 5.725 to 5.850 GHz U-NII-3/ISM 5.925 to 6.425 GHz U-NII-5 6.425 to 6.525 GHz U-NII-6 6.525 to 6.875 GHz U-NII-7 6.875 to 7.125 GHz U-NII-8 |
