Brand Name:
Huawei
Model Number:
S6730-S24X6Q
Document:
| Model | S6730-S24X6Q |
|---|---|
| Part Number | 02353AJW/02353AJW-001/02353AJW-003/02353AJW-004 |
| Memory | 4 GB |
| Flash Memory | 2 GB total (view available size via display version command) |
| PoE Support | Not supported |
| Weight with Packaging | 8.9 kg (19.62 lb) |
| Weight without Packaging | 5.62 kg (12.39 lb) |
| Dimensions (W x D x H) | 442 mm x 420 mm x 43.6 mm |
| Part Number | Remarks | Heat Dissipation | Input Voltage Range | Maximum Input Current | Operating Temperature | Operating Humidity |
|---|---|---|---|---|---|---|
| 02353AJW | / | Fan cooling with intelligent speed adjustment | AC: 90-290V AC; 45-65 Hz High-voltage DC: 190-290V DC DC: -38.4V to -72V DC |
Depends on pluggable power modules | -5°C to +45°C (23°F to 113°F) at 0-1800 m altitude | 5% to 95% RH, noncondensing |
| 02353AJW-001 | Some models cannot be downgraded due to component upgrades | Fan cooling with intelligent speed adjustment | AC: 90-290V AC; 45-65 Hz High-voltage DC: 190-290V DC DC: -38.4V to -72V DC |
Depends on pluggable power modules | -5°C to +45°C (23°F to 113°F) at 0-1800 m altitude | 5% to 95% RH, noncondensing |
| 02353AJW-003 | / | Air cooling with intelligent fan speed adjustment | AC: 90-290V AC; 45-65 Hz High-voltage DC: 190-290V DC DC: -38.4V to -72V DC |
Depends on pluggable power modules | -5°C to +45°C (23°F to 113°F) at 0-1800 m altitude | 5% to 95% RH, noncondensing |
| 02353AJW-004 | / | Air cooling with intelligent fan speed adjustment | AC: 90-290V AC; 45-65 Hz High-voltage DC: 190-290V DC DC: -38.4V to -72V DC |
Depends on pluggable power modules | -5°C to +45°C (23°F to 113°F) at 0-1800 m altitude | 5% to 95% RH, noncondensing |
| Model | Description |
|---|---|
| eSFP-GE-SX-MM850 | Optical Transceiver, eSFP, GE, Multi-mode Module (850nm, 0.55km, LC) |
| SFP-GE-LX-SM1310 | Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 10km, LC) |
| S-SFP-GE-LH40-SM1310 | Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 40km, LC) |
| S-SFP-GE-LH40-SM1550 | Optical Transceiver, eSFP, GE, Single-mode Module (1550nm, 40km, LC) |
| S-SFP-GE-LH80-SM1550 | Optical Transceiver, eSFP, GE, Single-mode Module (1550nm, 80km, LC) |
| eSFP-GE-ZX100-SM1550 | Optical Transceiver, eSFP, GE, Single-mode Module (1550nm, 100km, LC) |
| SFP-GE-LX-SM1310-BIDI | Optical Transceiver, eSFP, GE, BIDI Single-mode Module (TX1310/RX1490, 10km, LC) |
| SFP-GE-LX-SM1490-BIDI | Optical Transceiver, eSFP, GE, BIDI Single-mode Module (TX1490/RX1310, 10km, LC) |
| LE2MGSC40DE0 | Optical Transceiver, eSFP, GE, BIDI Single-mode Module (TX1310/RX1490, 40km, LC) |
| LE2MGSC40ED0 | Optical Transceiver, eSFP, GE, BIDI Single-mode Module (TX1490/RX1310, 40km, LC) |
| SFP-GE-ZBXD1 | Optical Transceiver, eSFP, GE, BIDI Single-mode Module (1570nm(Tx)/1490nm(Rx), 80km, LC) |
| SFP-GE-ZBXU1 | Optical Transceiver, eSFP, GE, BiDi Single-mode Module (1490nm(Tx)/1570nm(Rx), 80km, LC) |
| SFP-GE-BXU1-SC | 1000Base, BIDI Optical Transceiver, SFP, GE, Single-mode Module (TX1490nm/RX1310nm, 10km, SC) |
| CWDM-SFPGE-1471 | CWDM Optical Transceiver, eSFP, 2.5G, Single-mode Module (1471nm, 80km, LC) |
| CWDM-SFPGE-1491 | CWDM Optical Transceiver, eSFP, 2.5G, Single-mode Module (1491nm, 80km, LC) |
| CWDM-SFPGE-1511 | CWDM Optical Transceiver, eSFP, 2.5G, Single-mode Module (1511nm, 80km, LC) |
| CWDM-SFPGE-1531 | CWDM Optical Transceiver, eSFP, 2.5G, Single-mode Module (1531nm, 80km, LC) |
| CWDM-SFPGE-1551 | CWDM Optical Transceiver, eSFP, 2.5G, Single-mode Module (1551nm, 80km, LC) |
| CWDM-SFPGE-1571 | CWDM Optical Transceiver, eSFP, 2.5G, Single-mode Module (1571nm, 80km, LC) |
| CWDM-SFPGE-1591 | CWDM Optical Transceiver, eSFP, 2.5G, Single-mode Module (1591nm, 80km, LC) |
| CWDM-SFPGE-1611 | CWDM Optical Transceiver, eSFP, 2.5G, Single-mode Module (1611nm, 80km, LC) |
| DWDM-SFPGE-1560-61 | DWDM Optical Transceiver, eSFP, 2.5G, Single-mode Module (1560.61nm, 120km, LC) |
| SFP-1000BaseT | Electrical Transceiver, SFP, GE, Electrical Interface Module (100m, RJ45) |
| SFP-10G-USR | 10GBase-USR Optical Transceiver, SFP+, 10G, Multi-mode Module (850nm, 0.1km, LC) |
| OMXD30000 | Optical Transceiver, SFP+, 10G, Multi-mode Module (850nm, 0.3km, LC) |
| SFP-10G-iLR | Optical Transceiver, SFP+, 10G, Single-mode Module (1310nm, 1.4km, LC) |
| OSX010000 | Optical Transceiver, SFP+, 10G, Single-mode Module (1310nm, 10km, LC) |
| OSX040N01 | Optical Transceiver, SFP+, 10G, Single-mode Module (1550nm, 40km, LC) |
| SFP-10G-ER-1310 | Optical Transceiver, SFP+, 10G, Single-mode Module (1310nm, 40km, LC) |
| SFP-10G-ZR | 10GBase-ZR Optical Transceiver, SFP+, 10G, Single-mode Module (1550nm, 80km, LC) |
| SFP-10G-BXU1 | 10GBase, BIDI Optical Transceiver, SFP+, 10G, Single-mode Module (TX1270nm/RX1330nm, 10km, LC) |
| SFP-10G-BXD1 | 10GBase, BIDI Optical Transceiver, SFP+, 10G, Single-mode Module (TX1330nm/RX1270nm, 10km, LC) |
| SFP-10G-ER-SM1330-BIDI | Optical Transceiver, SFP+, 10G, BIDI Single-mode Module (TX 1330nm/RX 1270nm, 40km, LC) |
| SFP-10G-ER-SM1270-BIDI | Optical Transceiver, SFP+, 10G, BIDI Single-mode Module (TX 1270nm/RX 1330nm, 40km, LC) |
| SFP-10G-ZCW1471 | Optical Transceiver, SFP+, 10G, Single-mode Module (CWDM, 1471nm, 70km, LC) |
| SFP-10G-ZCW1491 | Optical Transceiver, SFP+, 10G, Single-mode Module (CWDM, 1491nm, 70km, LC) |
| SFP-10G-ZCW1511 | Optical Transceiver, SFP+, 10G, Single-mode Module (CWDM, 1511nm, 70km, LC) |
| SFP-10G-ZCW1531 | Optical Transceiver, SFP+, 10G, Single-mode Module (CWDM, 1531nm, 70km, LC) |
| SFP-10G-ZCW1551 | Optical Transceiver, SFP+, 10G, Single-mode Module (CWDM, 1551nm, 70km, LC) |
| SFP-10G-ZCW1571 | Optical Transceiver, SFP+, 10G, Single-mode Module (CWDM, 1571nm, 70km, LC) |
| SFP-10G-ZCW1591 | Optical Transceiver, SFP+, 10G, Single-mode Module (CWDM, 1591nm, 70km, LC) |
| SFP-10G-ZCW1611 | Optical Transceiver, SFP+, 10G, Single-mode Module (CWDM, 1611nm, 70km, LC) |
| QSFP-40G-SR4 | 40GBase-SR4 Optical Transceiver, QSFP+, 40G, Multi-mode (850nm, 0.15km, MPO) |
| QSFP-40G-iSR4 | 40GBase-iSR4 Optical Transceiver, QSFP+, 40G, Multi-mode (850nm, 0.15km, MPO) (Connect to four SFP+ Optical Transceiver) |
| QSFP-40G-eSR4 | 40GBase-eSR4 Optical Transceiver, QSFP+, 40G, Multi-mode (850nm, 0.3km, MPO) (Connect to four SFP+ Optical Transceiver) |
| QSFP-40G-iSM4 | 40GBase-iSM4 Optical Transceiver, QSFP+, 40G, Single-mode Module (1310nm, 1.4km, MPO) (Connect to four SFP+ Optical Transceiver) |
| QSFP-40G-eSM4 | 40GBase-eSM4 Optical Transceiver, QSFP+, 40G, Single-mode Module (1310nm, 10km, MPO) (Connect to four SFP+ Optical Transceiver) |
| Specification | S6720-30C-EI-24S-AC | S6730-S24X6Q |
|---|---|---|
| Switching Capacity | 2.56 Tbit/s | 960Gbps/2.4Tbps |
| Forwarding Performance | 720 Mpps | 480 Mpps |
| Fixed Ports | 24 x 10 GE SFP+, 2 x 40 GE QSFP+ | 24 x 10 Gig SFP+, 6 x 40 Gig QSFP+ |
| Power Supply | AC Power Supply | AC/DC Power Supply |
| Dimensions (W x D x H) | 442 mm x 420 mm x 44.4 mm | 442 mm x 420 mm x 43.6 mm |
| Input Voltage | AC: 100-240V AC, 50/60 Hz (Max: 90-264V AC) | AC: 100-240V AC, 50/60 Hz (Max: 90-290V AC, 45-65 Hz) DC: -48V to -60V DC (Max: -38.4V to -72V DC) |
