Brand Name:
Huawei
Model Number:
S5735S-L48T4X-A1
Document:
The Huawei Switch S5735S-L48T4X-A1 (Part Number: 98011338) is built on next-generation, high-performance hardware and powered by Huawei's Versatile Routing Platform (VRP). These CloudEngine S5735-L switches feature flexible Ethernet networking, diversified security control, and support for multiple Layer 3 routing protocols, providing higher performance and more powerful service processing capabilities for networks.
| Model | S5735S-L48T4X-A1 |
|---|---|
| Part Number | 98011338 |
| Description | S5735S-L48T4X-A1 (48*10/100/1000BASE-T ports, 4*10GE SFP+ ports, AC power) |
| First supported version | V200R020C10 |
| Memory | 512 MB |
| Flash memory | 512 MB |
| PoE | Not supported |
| Weight with packaging [kg(lb)] | 3.74 kg (8.25 lb) |
| Dimensions without packaging (H x W x D) [mm(in.)] |
Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.7 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 227.0 mm (1.72 in. x 17.4 in. x 8.94 in.) |
| (1) | Forty-eight 10/100/1000BASE-T ports | (5) | Ground screw |
| (2) | Four 10GE SFP+ ports | (6) | Jack for AC power cable locking strap |
| (3) | One console port | (7) | AC socket |
| (4) | One PNP button |
