Brand Name:
Huawei
Model Number:
S5735-S4T2X-IA150G1
Document:
| Model | S5735-S4T2X-IA150G1 |
|---|---|
| Part Number | 02312NTA |
| Description | Function Module, S5735-S4T2X-IA150G1, 220Vac Single-Phase Input, 144W Max Combined Output Power (12Vdc/24Vac), Natural Heat Dissipation |
| First Supported Version | V200R019C10 |
| Dimensions (H x W x D) | 550 mm x 300 mm x 135 mm (21.65 in. x 11.81 in. x 5.31 in.) |
| Memory | 1 GB |
| Flash Memory | 512 MB in total. To view the available flash memory size, run the display version command. |
| PoE Support | Not supported |
| (1) | Four 10/100/1000BASE-T ports |
| (2) | Two 10GE SFP+ ports |
| (3) | One ETH management port |
| (4) | One console port |
| (5) | Monitoring port DI: signal input line, which connects to a door status sensor DO: signal output line, which connects to a camera alarm signal cable |
| (6) | 220 V AC power input socket |
| (7) | Fiber management tray (FMT) |
| (8) | 220 V AC power input circuit breaker |
| (9) | 220 V AC power output circuit breaker |
| (10) | 12 V DC power output socket |
| (11) | 24 V AC power output socket |
| (12) | PE cable ground terminal |
| (13) | Door status sensor |
| (14) | Ground screw |
| (15) | Cable outlet |
