Brand Name:
Huawei
Model Number:
S5735-S24P4XE-V2
Document:
| Specification | Details |
|---|---|
| Model | S5735-S24P4XE-V2 |
| Part Number | 98012030 |
| Description | S5735-S24P4XE-V2 (24×10/100/1000BASE-T ports, 4×10GE SFP+ ports, 2×12GE stack ports, PoE+, without power module) |
| Dimensions | Basic: 43.6 × 442.0 × 420.0 mm (1.72 × 17.40 × 16.54 in.) Maximum: 43.6 × 442.0 × 446.0 mm (1.72 × 17.40 × 17.56 in.) |
| Weight | 7.74 kg (17.06 lb) |
| Typical Power Consumption | 39.43 W |
| Maximum Power Consumption | Without PoE: 45.80 W (600W AC) / 55.70 W (1000W AC) / 64.68 W (1000W DC) Full PoE Load: 1023.22 W (PoE: 840 W, with three 1000 W AC power modules) |
| Memory | 2 GB |
| Flash Memory | 1 GB physical space |
| PoE Support | Yes |
| Indicator | Name | Status | Description |
|---|---|---|---|
| PWR | Power Module | Off / Green / Yellow | Power status: Off (powered off), Green (normal), Yellow (module issues) |
| SYS | System Status | Off / Green / Red | System operation: Off (not running), Green (starting/running), Red (alarm/failure) |
| MST | Stack | Off / Green | Stack configuration: Off (standby/slave), Green (master/selected) |
| PoE | PoE | Off / Green | PoE mode selection and port status display |
| ID | ID | Off / Blue | Maintenance identification: Blue indicates switch to maintain |
| USB | USB Deployment | Off / Green / Red | USB deployment status: Off (no drive), Green (success/in progress), Red (failure) |
