Brand Name:
Huawei
Model Number:
S5735-S48T4XE-V2
Document:
| Model | S5735-S48T4XE-V2 |
|---|---|
| Part Number | 98012044 |
| Description | S5735-S48T4XE-V2 (48*10/100/1000BASE-T ports, 4*10GE SFP+ ports, 2*12GE stack ports, without power module) |
| Dimensions without packaging (H x W x D) [mm(in.)] |
Basic dimensions (excluding protruding parts): 43.6 mm x 442.0 mm x 420.0 mm (1.72 in. x 17.40 in. x 16.54 in.) Maximum dimensions (including protruding parts): 43.6 mm x 442.0 mm x 446.0 mm (1.72 in. x 17.40 in. x 17.56 in.) |
| Weight with packaging [kg(lb)] | 7.74 kg (17.06 lb) |
| Typical power consumption [W] | 39.10 W |
| Maximum power consumption [W] |
55.12 W (with two 80 W AC power modules) 64.51 W (with two 180 W AC power modules) 93.26 W (with two 1200 W DC power modules) |
| Memory | 2 GB |
| Flash memory | Physical space: 1 GB |
| PoE | Not supported |
| (1) | Forty-eight 10/100/1000BASE-T ports | (6) | One MODE button |
| (2) | Four 10GE SFP+ ports | (7) | One PNP button |
| (3) | Two stack ports | (8) | Ground screw |
| (4) | One console port | (9) | Power module slot 1 |
| (5) | One USB port | (10) | Power module slot 2 |
