Brand Name:
Huawei
Model Number:
S5720-52P-PWR-LI-AC
Document:
| Model | S5720-52P-PWR-LI-AC |
| Part Number | 98010776 |
| Memory (RAM) | 512 MB |
| Flash Memory | 512 MB total (view available size using display version command) |
| PoE Support | PoE+ |
| Weight with Packaging | 5.6 kg (12.35 lb) |
| Dimensions (H x W x D) |
Basic: 43.6 mm x 442.0 mm x 314.8 mm (1.72 in. x 17.4 in. x 12.39 in.) Maximum: 43.6 mm x 442.0 mm x 323.8 mm (1.72 in. x 17.4 in. x 12.75 in.) |
| Forwarding Performance | 87 Mpps / 144 Mpps |
| Switching Capacity | 336 Gbit/s |
| eSFP-GE-SX-MM850 | Optical Transceiver, eSFP, GE, Multi-mode Module (850nm, 0.5km, LC) |
| SFP-GE-LX-SM1310 | Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 10km, LC) |
| S-SFP-GE-LH40-SM1310 | Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 40km, LC) |
| SFP-1000BaseT | 1000BASE-T (RJ45) SFP Electrical Module, Auto Negotiate, 100m |
| SFP-6GE-LR | 6GBase-LR Optical Transceiver, SFP, 6G, Single-mode Module (1310nm, 2km, LC) |
| SFP-10G-USR | 10GBase-USR Optical Transceiver, SFP+, 10G, Multi-mode Module (850nm, 0.1km, LC) |
| eSFP-GE-ZX100-SM1550 | eSFP, GE, Single-mode Module (1550nm, 100km, LC) |
| SFP-GE-LX-SM1310-BIDI | BiDi Transceiver, eSFP, Tx1310nm/Rx1490nm, 1.25Gb/s, LC, SM, 10km |
| SFP-GE-LX-SM1490-BIDI | BiDi Transceiver, eSFP, Tx1490nm/Rx1310nm, 1.25Gb/s, LC, SM, 10km |
| SFP-GE-ZBXD1 | Huawei Optical Transceiver SFP-GE-ZBXD1, eSFP, GE, BIDI Single-mode Module (1570nm/1490nm, 80km, LC) |
| Feature | S5720-52P-PWR-LI-AC | S5720-52P-LI-AC |
|---|---|---|
| Ports | 48 Ethernet 10/100/1000 Base-T ports, 4 Gig SFP ports | 48 Ethernet 10/100/1000 Base-T ports, 4 Gig SFP ports |
| Power | AC power supply, supporting RPS (redundant power supply) | AC power supply, supporting RPS (redundant power supply) |
| PoE Support | PoE+ | N/A |
| Forwarding Performance | 87 Mpps / 144 Mpps | 87 Mpps / 144 Mpps |
| Switching Capacity | 336 Gbit/s | 336 Gbit/s |
