Brand Name:
Huawei
Model Number:
S5720-56C-HI-AC
Document:
| Model | S5720-56C-HI-AC |
|---|---|
| Part Number | 02358598 |
| Memory (RAM) | 4 GB |
| Flash | 512 MB total (view available flash memory using display version command) |
| PoE | Not supported |
| Weight with packaging | 10 kg (22.05 lb) |
| Dimensions (H x W x D) |
Basic: 44.4 mm x 442.0 mm x 424.7 mm (1.75 in. x 17.4 in. x 16.72 in.) Maximum: 44.4 mm x 442.0 mm x 451.8 mm (1.75 in. x 17.4 in. x 17.79 in.) |
| Model | Description |
|---|---|
| SFP-10G-USR | 10GBase-USR Optical Transceiver, SFP+, 10G, Multi-mode Module (850nm, 0.1km, LC) |
| OMXD30000 | Optical Transceiver, SFP+, 10G, Multi-mode Module (850nm, 0.3km, LC) |
| OSX010000 | Optical Transceiver, SFP+, 10G, Single-mode Module (1310nm, 10km, LC) |
| Model | Description |
|---|---|
| PAC-600WA-B | 600W AC Power Module (Back to Front, Power panel side exhaust) |
| PDC-350WA-B | 350W DC Power Module (Back to Front, Power panel side exhaust) |
| Model | Description |
|---|---|
| eSFP-GE-SX-MM850 | Optical Transceiver, eSFP, GE, Multi-mode Module (850nm, 0.55km, LC) |
| SFP-GE-LX-SM1310 | Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 10km, LC) |
| S-SFP-GE-LH40-SM1310 | Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 40km, LC) |
| S-SFP-GE-LH40-SM1550 | Optical Transceiver, eSFP, GE, Single-mode Module (1550nm, 40km, LC) |
| SFP-1000BaseT | Electrical Transceiver, SFP, GE, Electrical Interface Module (100m, RJ45) |
| Feature | S5720-56C-HI-AC | S5720-56C-PWR-HI-AC |
|---|---|---|
| Fixed Ports | 48 x 10/100/1,000 Base-T, 4 x 10 GE SFP+ | 48 x 10/100/1,000 Base-T, 4 x 10 GE SFP+ |
| Power Supply | 600W AC power supply | 600W/1,150W AC power supply |
| Forwarding Performance | 192 Mpps | 192 Mpps |
| Switching Capacity | 598 Gbit/s | 598 Gbit/s |
| PoE | Not supported | Supported |
| Power Consumption | < 183.3W | Without PD: < 188.74W, With PD: < 1,739W (device: 299W, PD: 1,440W) |
