Brand Name:
Huawei
Model Number:
S5720-28X-SI-24S-AC
Document:
| Model | S5720-28X-SI-24S-AC |
|---|---|
| Part Number | 98010625 |
| Memory (RAM) | 512 MB |
| Flash Memory | 512 MB total. To view available flash memory size, run the display version command. |
| PoE Support | Not supported |
| Weight with Packaging | 4.1 kg (9.04 lb) |
| Dimensions (H × W × D) |
Basic dimensions: 43.6 mm × 442.0 mm × 224.8 mm (1.72 in. × 17.4 in. × 8.85 in.) Maximum dimensions: 43.6 mm × 442.0 mm × 233.8 mm (1.72 in. × 17.4 in. × 9.21 in.) |
| Port Number | Port Type & Description |
|---|---|
| ① | Sixteen 100/1000BASE-X ports |
| ② | Eight combo ports (10/100/1000BASE-T + 100/1000BASE-X) |
| ③ | Four 10GE SFP+ ports |
| ④ | One ETH management port |
| ⑤ | One console port |
| ⑥ | One USB port |
| ⑦ | AC socket |
| ⑧ | Jack for AC power cable locking strap |
| ⑨ | Ground screw |
| ⑩ | RPS socket |
