Brand Name:
Huawei
Model Number:
LS-S2309TP-PWR-EI
Document:
| Feature | Specification |
|---|---|
| Ports | 8x 10/100Base-TX ports, 1x gigabit Combo port (10/100/1000Base-T or 100/1000Base-X) |
| Forwarding Performance | 2.7 Mpps |
| Port Switching Capacity | 3.6 Gbit/s |
| Backplane Switching Capacity | 32 Gbit/s |
| MAC Address Table | 8K entries with advanced management features |
| VLAN Features | Supports 4096 VLANs with multiple VLAN types and switching |
| QoS | Advanced traffic management with multiple queuing algorithms |
| Power Supply | AC: 100-240V, 50/60Hz; PoE power: 124W |
| Dimensions | 320mm x 220mm x 43.6mm |
| Weight | < 2.5kg |
| Type | Model | Description |
|---|---|---|
| FE-SFP Optical Transceiver | SFP-FE-SX-MM1310 | 100M/155M, Multi-mode (1310nm, 2km, LC) |
| eSFP-FE-LX-SM1310 | 100M/155M, Single-mode (1310nm, 15km, LC) | |
| S-SFP-FE-LH40-SM1310 | FE, Single-mode (1310nm, 40km, LC) | |
| GE-SFP Optical Transceiver | eSFP-GE-SX-MM850 | GE, Multi-mode (850nm, 0.55km, LC) |
| SFP-GE-LX-SM1310 | GE, Single-mode (1310nm, 10km, LC) | |
| S-SFP-GE-LH40-SM1310 | GE, Single-mode (1310nm, 40km, LC) | |
| S-SFP-GE-LH40-SM1550 | GE, Single-mode (1550nm, 40km, LC) | |
| GE Copper Transceiver | SFP-1000BaseT | GE, Electrical Interface (100m, RJ45) |
| Feature | LS-S2309TP-PWR-EI | LS-S2309TP-EI-DC |
|---|---|---|
| Ports | 8x 10/100BASE-T, 1x Combo port | 8x 10/100BASE-T, 1x Combo port |
| Power Supply | AC with PoE support | DC without PoE |
| Power Consumption | 154W (PoE: 124W) | 12.8W |
| Dimensions | 320mm x 220mm x 43.6mm | 250mm x 180mm x 43.6mm |
| Weight | < 2.5kg | 1.4kg |
