Brand Name:
Huawei
Model Number:
LS-S2318TP-SI-AC
Document:
| Specification | Details |
|---|---|
| Port Configuration | 16 x 10/100Base-TX ports, 2 x gigabit Combo ports (10/100/1000Base-T or 100/1000Base-X) |
| Forwarding Performance | 5.4 Mpps |
| Port Switching Capacity | 7.2 Gbit/s |
| Backplane Switching Capacity | 32 Gbit/s |
| MAC Address Table | 8K entries with advanced management features |
| VLAN Support | IEEE 802.1Q with 4096 VLANs |
| QoS Features | Port rate limiting, traffic prioritization, and multiple queue algorithms |
| IPv6 Support | Host functions and static routing |
| Dimensions | 442 x 220 x 43.6 mm (W x D x H) |
| Weight | < 2.4 kg |
| Power Consumption | < 14.5 W |
| Module Type | Model | Description |
|---|---|---|
| FE-SFP Optical Transceiver | SFP-FE-SX-MM1310 | 100M/155M Multi-mode (1310nm, 2km, LC) |
| eSFP-FE-LX-SM1310 | 100M/155M Single-mode (1310nm, 15km, LC) | |
| S-SFP-FE-LH40-SM1310 | FE Single-mode (1310nm, 40km, LC) | |
| GE-SFP Optical Transceiver | eSFP-GE-SX-MM850 | GE Multi-mode (850nm, 0.55km, LC) |
| SFP-GE-LX-SM1310 | GE Single-mode (1310nm, 10km, LC) | |
| S-SFP-GE-LH40-SM1310 | GE Single-mode (1310nm, 40km, LC) | |
| S-SFP-GE-LH40-SM1550 | GE Single-mode (1550nm, 40km, LC) | |
| GE Copper Transceiver | SFP-1000BaseT | GE Electrical Interface (100m, RJ45) |
| Feature | LS-S2318TP-SI-AC | LS-S2309TP-PWR-EI |
|---|---|---|
| Fixed Ports | 16 x 10/100 + 2 x Combo GE | 8 x 10/100 + 1 x Combo GE |
| Forwarding Performance | 5.4 Mpps | 2.7 Mpps |
| Port Switching Capacity | 7.2 Gbit/s | 3.6 Gbit/s |
| Power Consumption | < 14.5 W | 154 W |
| PoE Support | No | Yes (124W available) |
| Dimensions | 442 x 220 x 43.6 mm | 320 x 220 x 43.6 mm |
