Place of Origin:
China
Brand Name:
ZTE
Certification:
CE
Model Number:
GFCH
Document:
| Brand | ZTE |
| Model Name | GFCH |
| Port | 16-port |
| Interface | XG-PON & GPON Combo |
| Function | XG-PON & GPON service access |
| Specification | XG-PON & GPON Combo SFP+ interface, with built-in internal multiplexing, SC/UPC optical connector |
| Management and control module | Configures, controls, and manages the card |
| PONMAC module | Implements all functions on the GPON layer defined in ITU-T G.984.3 and the XGS-PON layer defined by ITU-T G.989.3 and ITU-T G.987.3 |
| NP module | Implements data processing on the service layer, including service bandwidth and QoS processing based on service types and user needs to meet SLA requirements (complies with TR156) |
| Optical module | Provides GPON optical interface compliant with ITU-T G.984.2 or XGS-PON optical interface compliant with ITU-T G.9807 |
| Clock module | Processes system clock in compliance with ITU-T G.8262, G.8264, and G.781 |
| Weight | 1.72 kg |
| Dimensions (L × H × W) | 393.1 mm × 23.9 mm × 214 mm |
