Name: Multimode 10G SFP+ Transceiver Module 02310QBJ 02310QDT BX10-D BiDi 1270nm-RX Simplex LC
Brand: Hangzhou Nanyin Trading Co., Ltd.
SKU: 02310QBJ 02310QDT SFP-10G-BXD1
Price: 35 USD
Availability: InStock

Home > Products > Huawei SFP >

Multimode 10G SFP+ Transceiver Module 02310QBJ 02310QDT BX10-D BiDi 1270nm-RX Simplex LC

BXD1 10g sfp+ transceiver

BiDi Simplex LC 10g sfp+ transceiver

1270nm multimode sfp module

Place of Origin:

China

Brand Name:

Huawei

Certification:

Model Number:

02310QBJ 02310QDT SFP-10G-BXD1

Chat Now

Request A Quote

Product Details

Condition:

Genuine New

Dimensions:

13.4 Mm X 56.5 Mm X 8.5 Mm

Transmissiondistance:

Up To 10 Km (model Dependent)

Compliancestandards:

RoHS, IEEE 802.3, MSA

Connectortype:

Mtbf:

Over 1 Million Hours

Operatingtemperature:

-40°C To 85°C

Productname:

Huawei SFP

Datarate:

1.25 Gbps

Hotpluggable:

Yes

Powerconsumption:

< 1 W

Producttype:

Small Form-factor Pluggable (SFP) Transceiver

Interface:

SFP Electrical Interface

Compatibility:

Huawei Switches, Routers, And Optical Modules

Protocolsupport:

Ethernet, Fibre Channel, SONET/SDH

Wavelength:

850 Nm / 1310 Nm / 1550 Nm (depending On Model)

Highlight:

BXD1 10g sfp+ transceiver

BiDi Simplex LC 10g sfp+ transceiver

1270nm multimode sfp module

Payment & Shipping Terms

Minimum Order Quantity

2pcs

Price

$35

Packaging Details

Optic Box

Delivery Time

3-5 working days

Payment Terms

T/T,Western Union,MoneyGram

Supply Ability

200 Pairs

Genuine Huawei SFP-GE-LX-SM1310 02313URF 1000BASE-LX/LH SFP 1310nm 10km DOM Duplex LC MMF

Chat Now

Industrial Huawei 023RAV 10g Copper SFP 100m OEGD01N01 RJ45 Transceiver Module

Chat Now

0231A563 rJ45 Huawei SFP-GE-LX-SM1310-A Optical Transceiver 1.25G-LX10 1000BASE-LX/LH

Chat Now

02313URK Huawei Transceiver OSX010000 Original New SFP+ 1310nm 10km DOM SMF Duplex LC

Chat Now

86-180-5715-6223

info@hi-network.com

Chat Now

Product Description

Multimode 10G SFP+ Transceiver Module

Huawei SFP-10G-BXD1 02310QBJ 02310QDT 10GBASE-BX SFP+ Transceiver Module

This 10G BiDi SFP+ transceiver supports up to 10km link lengths over OS2 single-mode fiber via an LC simplex connector. Featuring bidirectional data transmission over a single strand of fiber, this module transmits at 1330nm and receives at 1270nm wavelengths.

Key Features:

Bidirectional transmission over single fiber strand
Digital diagnostics monitoring via I2C interface (SFF-8472 compliant)
Low power consumption (≤1W typical)
Compatible with switches, routers, servers, and network interface cards
Ideal for enterprise wiring closets and service provider transport applications

Technical Specifications

Model Numbers	SFP-10G-BXD1, 02310QBJ, 02310QDT
Vendor	Huawei
Form Factor	SFP+
Max Data Rate	11.3168Gbps
Wavelength	1330nm-TX/1270nm-RX
Max Cable Distance	10km
Connector	Simplex LC
Fiber Type	Single-Mode Fiber (SMF)
Transmitter Type	DFB
Receiver Type	PIN
TX Power	-8.2~0.5dBm
Receiver Sensitivity	< -14.4dBm
Power Budget	6.2dB
Receiver Overload	0.5dBm
Typical Power Consumption	≤1W
Extinction Ratio	>3.5dB
Operating Temperature	0 to 70°C (32 to 158°F)
Protocols & Standards	SFP+ MSA Compliant, CPRI, eCPRI

Each BiDi SFP+ transceiver module is individually tested and validated for reliable performance in various network environments including Radio & Baseband Units and transport applications.
