Place of Origin:
China
Brand Name:
H3C
Certification:
CE
Model Number:
0231A563/ SFP-GE-LX-SM1310-A
| Model Name | SFP-GE-LX-SM1310-A / 231A563 |
| Vendor | Huawei |
| Form Factor | SFP |
| Max Data Rate | 1.25Gbps |
| Wavelength | 1310nm |
| Max Distance | 10km over Single-Mode Fiber |
| Connector | Duplex LC |
| Fiber Type | Single-Mode Fiber (SMF) |
| Transmitter Type | FP |
| Receiver Type | PIN |
| DDM/DOM Support | Yes |
| Operating Temperature | 0 to 70°C (32 to 158°F) |
| TX Power | -9.5 to -3dBm |
| Receiver Sensitivity | < -20dBm |
| Power Consumption | ≤1W |
| Receiver Overload | -3dBm |
| Bit Error Ratio | 1E-12 |
| Extinction Ratio | >9dB |
| EMC Compliance | Supported |
| MTBF | 4,761,904 Hours |
| Protocol Standards | IEEE 802.3ah-2004, IEEE 802.3z, SFF-8472, SFP MSA (INF-8074i) |
| Warranty | 3 Years |
