Brand Name:
Huawei
Model Number:
S1720-20GFR-4TP
Document:
| Model | S1720-20GFR-4TP |
|---|---|
| Part Number | 98010750 |
| First Supported Version | V200R006C10 |
| Description | S1720-20GFR-4TP (16 Ethernet 10/100/1000 ports, 2 Gig SFP and 2 dual-purpose 10/100/1000 or SFP, AC 110/220V) |
| Memory | 256 MB |
| Flash Memory | 200 MB |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.) |
| Relative Humidity | 5% to 95%, non-condensing |
| (1) | Sixteen 10/100/1000BASE-T ports | (6) | Mode switching button |
| (2) | Two 1000BASE-X Ethernet ports | (7) | Ground screw |
| (3) | Two combo ports (10/100/1000BASE-T + 100/1000BASE-X) | (8) | Jack reserved for AC power cable locking strap |
| (4) | One console port | (9) | AC power socket |
| (5) | Reset button |
