Place of Origin:
China
Brand Name:
HUAWEI
Certification:
CE
Model Number:
MA5800X2
Document:
| Slot Type | Slot No. | Total |
|---|---|---|
| Control board (SCU) slot | 2,3 | 2 |
| Power board slot | 0 | 1 |
| Service board slot | 1,2 | 2 |
| Model | Huawei SmartAX EA5800-X2 IEC |
|---|---|
| Supported Cabinets | N63E-22 |
| Dimensions | 2U high and 19 inches wide |
| Dimensions (H x W x D) |
Excluding mounting brackets: 442 mm x 268.7 mm x 88.1 mm Including IEC mounting brackets: 482.6 mm x 268.7 mm x 88.1 mm Including ETSI mounting brackets: 535 mm x 268.7 mm x 88.1 mm |
| Maximum Weight (including mounting brackets) | 9.4 kg |
| Power Supply Mode |
DC power supply (dual backup) AC power supply + battery for backup |
| Maximum Input Current |
DC power supply: 20A AC power supply: 8A |
| Model Name | Description |
|---|---|
| H902MPLAE | Huawei SmartAX EA5800 Main Processing Board |
| H901MPSCE | Huawei SmartAX EA5800 Main Processing Board |
| H901CIUA | Huawei SmartAX EA5800 Combo Interface Transfer Board |
| H901XGHDE | Huawei SmartAX EA5800 8-port Advanced XG-PON OLT Interface Board |
| H9010GHK | Huawei SmartAX EA5800 48-port Advanced GE/FE Optical Interface Board |
| H9010XHD | Huawei SmartAX EA5800 8-port Advanced 10GE Optical Interface Board |
| H9020XHD | Huawei SmartAX EA5800 8-port Advanced 10GE Optical Interface Board |
| H901GPSFE | Huawei SmartAX EA5800 16-port GPON OLT Interface Board |
| H9010XEG | Huawei SmartAX EA5800 24 port Aggregationed 10GE/GE Optical Interface Board |
| H901TWEDE | Huawei SmartAX EA5800 8-port Enhanced XGS-PON OLT Interface Board |
| H901XSHF | Huawei SmartAX EA5800 16-port XGS-PON OLT Interface Board |
| H902GPHFE | Huawei SmartAX EA5800 16-port GPON OLT Interface Board |
| H901NXED | Huawei SmartAX EA5800 8-port Enhanced 10GE Uplink Interface Board |
| H901PILA | Huawei SmartAX EA5800 Power Transfer Board |
| H901PISA | Huawei SmartAX EA5800 Power Transfer Board |
| H901PISB | Huawei SmartAX EA5800 Power Transfer Board |
| H902PISB | Huawei SmartAX EA5800 Power Transfer Board |
| H901FMSA | Huawei SmartAX EA5800 EA5800-X2 fan tray |
| Parameters | MA5800-X17 | MA5800-X15 | MA5800-X7 | MA5800-X2 |
|---|---|---|---|---|
| Board Configuration | Control board slots: 9, 10 Service board slots: 1-8, 11-19 Universal interface board slot: 0 Power board slots: 20, 21 |
Control board slots: 8, 9 Service board slots: 1-7, 10-17 Universal interface board slot: 0 Power board slots: 18, 19 |
Control board slots: 8, 9 Service board slots: 1-7 Universal interface board slot: 0 Power board slots: 10, 11 |
Control board slots: 3, 4 Service board slots: 1-2 No universal interface board Power board slot: 0 |
| Switching Capacity (load sharing) | 3.6 Tbit/s | 3.6 Tbit/s | 3.6 Tbit/s | 480 Gbit/s |
| Maximum Bandwidth per Service Slot | 100 Gbit/s | 100 Gbit/s | 100 Gbit/s | 80 Gbit/s |
| Layer 2 Packet Forwarding Rate | 5,298 Mpps | 5,298 Mpps | 5,298 Mpps | 714 Mpps |
| Max Concurrent 4K Video Users | 16,000 | 16,000 | 8,000 | 2,000 |
| Max MAC Addresses | 262,143 | 262,143 | 262,143 | 262,143 |
| Max ARP/Routing Entries | 131,072 | 131,072 | 131,072 | 131,072 |
| GPON/XG(S)-PON Ports | 272 | 240 | 112 | 32 |
| GE/FE Ports | 816 | 720 | 336 | 96 |
| 10 GE Ports | 408 | 360 | 168 | 16 |
