Place of Origin:
China
Brand Name:
Huawei
Certification:
CE
Model Number:
EA5801-CG08-AC
Document:
| Model | Huawei SmartAX EA5801-CG04-AC ETSI |
|---|---|
| Dimensions (H × W × D) |
Without mounting ears: 43.6 mm × 442 mm × 222.3 mm With IEC-standard mounting ears: 43.6 mm × 482.6 mm × 222.3 mm With ETSI-standard mounting ears: 43.6 mm × 535 mm × 222.3 mm |
| Power Supply Mode | AC power supply (dual for backup) |
| Working Voltage Range | AC power supply: 100V to 240V |
| Rated Voltage | AC power supply: 110V/220V |
| Maximum Input Current | AC power supply: 2.5A |
| MAC Addresses | 32,768 |
| ARP Table | 16,384 |
| GE Upstream Ports | 2 optical/electrical combo ports |
| 10 GE/GE Upstream Ports | 2 |
| Number of Service Ports | 4 x G-PON and GPON combo |
| Feature | EA5801-GP08-AC | EA5801-GP08-DC | EA5801-CG04-AC | EA5801-CG04-DC |
|---|---|---|---|---|
| Power Supply Mode | AC power supply (dual for backup) | DC power supply (dual for backup) | AC power supply (dual for backup) | DC power supply (dual for backup) |
| Working Voltage Range | 100V to 240V | -38.4V to -72V | 100V to 240V | -38.4V to -72V |
| Rated Voltage | 110V/220V | -48V/-60V | 110V/220V | -48V/-60V |
| Maximum Input Current | 2.5A | 6A | 2.5A | 6A |
| MAC Addresses | 32,768 | 32,768 | 32,768 | 32,768 |
| ARP Table | 16,384 | 16,384 | 16,384 | 16,384 |
| GE Upstream Ports | 2 optical/electrical combo ports | 2 optical/electrical combo ports | 2 optical/electrical combo ports | 2 optical/electrical combo ports |
| 10 GE/GE Upstream Ports | 2 | 2 | 2 | 2 |
| Number of Service Ports | 8 x GPON | 8 x GPON | 4 x G-PON and GPON combo | 4 x G-PON and GPON combo |
