Place of Origin:
China
Brand Name:
Huawei
Certification:
CE
Model Number:
S5735I-S8T8P2S4XN-V2
Document:
| Item | Details |
|---|---|
| Description | S5735I-S8T8P2S4XN-V2 (16*10/100/1000BASE-T ports,8*POE+,2*GE SFP ports, 4*10GE SFP+ ports, DIN Rail Mounting, Dual redundant 54 to 57V DC power, Fanless) |
| Part Number | 98012426 |
| Model | S5735I-S8T8P2S4XN-V2 |
| First supported version | V600R024C00 |
|
1 |
Two DC power input ports NOTE:
The following external power module can be configured: PAC240S56-CN (240 W PoE AC&HVDC Power) |
2 |
DI port |
|
3 |
DO port |
4 |
RS485 port |
|
5 |
One console port |
6 |
One USB port |
|
7 |
Ground screw NOTE:
It is used with a ground cable. |
8 |
Eight 10/100/1000BASE-T ports |
|
9 |
Four 10GE SFP+ ports |
10 |
Eight 10/100/1000BASE-T PoE+ ports NOTE:
You can run the port combination-mode command to configure the working mode of GE electrical ports, GE optical ports, and 10GE SFP+ Ethernet optical ports. By default, the M0 mode (8 x GE electrical ports and 2 x GE/FE optical ports) is used. You can also change this mode to M1 mode (4 x GE electrical ports + 2 x GE/10GE optical ports).
|
|
11 |
Two 1000BASE-X ports or two 10GE SFP+ ports NOTE:
You can run the port combination-mode command to configure the working mode of GE electrical ports, GE optical ports, and 10GE SFP+ Ethernet optical ports. By default, the M0 mode (8 x GE electrical ports and 2 x GE/FE optical ports) is used. You can also change this mode to M1 mode (4 x GE electrical ports + 2 x GE/10GE optical ports).
|
12 |
- |
| Port | Connector Type | Description | Available Components |
|---|---|---|---|
| 10/100/1000BASE-T port | RJ45 | A 10/100/1000BASE-T Ethernet electrical port sends and receives service data at 10/100/1000 Mbit/s. |
Ethernet cable |
| 10GE SFP+ optical port | SFP+ | A 10GE SFP+ Ethernet optical port supports auto-sensing to 1000 Mbit/s. It sends and receives service data at 1000 Mbit/s or 10 Gbit/s. |
|
| 100/1000BASE-X port | SFP |
A 100/1000BASE-X port can send and receive data at 100 Mbit/s or 1000 Mbit/s. By default, the port works as a 100/1000BASE-X port. You can run the port combination-mode command to switch the working mode to 10GE SFP+. After the switching, GE electrical ports 13 to 16 are unavailable. |
|
| Console port | RJ45 | The console port is connected to a console for on-site configuration. |
Console cable |
| USB port | USB 2.0 Type A |
The USB port can have a USB flash drive connected to upgrade the switch, or transfer configuration files or other files. The USB port can only connect to a USB flash drive that complies with USB 2.0. USB flash drives from different vendors differ in model compatibility and drivers. If a USB flash drive cannot be used, try to replace it with another one from a mainstream vendor. |
USB flash drive |
| RS-485 port | 2x5-Pin Phoenix Connector |
The RS-485 port is used for data collection.
The default configurations of the RS-485 port are as follows:
|
2x5-Pin Phoenix Connector |
| DI port | 2x5-Pin Phoenix Connector |
The DI port is used to check remote communication input and level signals. Signal type: Passive DI signals, Boolean value (short circuit and open circuit) |
2x5-Pin Phoenix Connector |
| DO port | 2x5-Pin Phoenix Connector |
The DO port outputs signals so that the connected device can take corresponding actions. Signal type: Passive DO signals, Boolean value (short circuit and open circuit) External power supply: voltage less than 60 V DC and circuit current less than 0.5 A |
2x5-Pin Phoenix Connector |
|
No. |
Indicator |
Name |
Color |
Status |
Description |
|---|---|---|---|---|---|
|
1 |
PWR1 |
Indicator of power module 1 |
- |
Steady off |
Power module 1 is not supplying power or is abnormal. |
|
Green |
Steady on |
Power module 1 is supplying power properly. |
|||
|
2 |
PWR2 |
Indicator of power module 2 |
- |
Steady off |
Power module 2 is not supplying power or is abnormal. |
|
Green |
Steady on |
Power module 2 is supplying power properly. |
|||
|
3 |
SYS |
System status indicator |
- |
Steady off |
The system is not running. |
|
Green |
Fast blinking |
The system is starting. |
|||
|
Green |
Steady on |
In the system startup preparation phase, the SYS indicator is steady green for no more than 30 seconds. |
|||
|
Green |
Slow blinking |
The system is running properly. |
|||
|
Red |
Steady on |
The system does not work normally after registration. |
|||
|
4 |
MST |
Stack indicator |
- |
Steady off |
The device is not a stack master. |
|
Green |
Blinking |
The device is a stack master or the stack is not deployed. |
|||
|
5 |
USB |
USB-based deployment indicator |
- |
Steady off |
No USB flash drive is installed, or the indicator fails. |
|
Green |
Steady on |
USB-based deployment succeeds. If there is no deployment configuration file, deployment will be repeatedly performed. In this case, the indicator is also steady green. |
|||
|
Green |
Blinking |
USB-based deployment is ongoing. |
|||
|
Red |
Steady on |
USB-based deployment fails. |
|||
|
6 |
1 to 16 |
Electrical port indicator (one indicator for each port) |
For ports 9 to 16, arrowheads show their positions. A down arrowhead indicates a port at the bottom, and an up arrowhead indicates a port at the top. |
Meanings of service port indicators vary in different modes. For details, see Table 4-1352. |
|
|
7 |
1 to 6 17 and 18 |
Optical port indicator (one indicator for each port) |
- |
||
|
8 |
9 to 16 |
Service port PoE status indicator |
- |
Steady off |
The port is not supplying power to a powered device (PD). |
|
Green |
Steady on |
The port is supplying power to a PD. |
|||
|
Green |
Blinking |
The PD connected to the port is not an IEEE-compliant PD or its power exceeds the maximum power or power threshold of the port. |
|||
|
Display Mode |
Color |
Status |
Description |
|---|---|---|---|
|
Default mode |
- |
Off |
The port is not connected or has been shut down. |
|
Green |
Steady on |
A link has been established on the port. |
|
|
Green |
Blinking |
The port is sending or receiving data. |
The device can use a single power module or dual power modules for 1+1 power redundancy.
It can be directly connected to an external 56 V DC power module or a PAC240S56-CN power module.
|
Power Module 1 |
Power Module 2 |
Available PoE Power |
Maximum Number of Ports (Fully Loaded) |
|---|---|---|---|
|
PAC240S56-CN |
- |
200 W |
|
|
- |
PAC240S56-CN |
200 W |
|
|
PAC240S56-CN |
PAC240S56-CN |
240 W |
|
|
External 56 V DC power module |
- |
240 W (maximum) |
|
|
- |
External 56 V DC power module |
240 W (maximum) |
|
|
External 56 V DC power module |
External 56 V DC power module |
240 W (maximum) |
|
