Brand Name:
Finisar
Model Number:
FTLF8528P3BCV-QL
Document:
| Model | FTLF8528P3BCV-QL |
| Description | Finisar SW 4x Channel 850NM SFP Fiber 8Gb Transceiver Optical |
| Temperature Range | Commercial -5° to 70°C |
| Connectors | Double LC |
| Tx Wavelength Bandwidth | 20 nm (840-860 nm) |
| Rx Wavelength Bandwidth | 20 nm (840-860 nm) |
| Minimum Transmitting Power | -6.5 dB |
| Maximum Transmitting Power | 1 dB |
| Receiver Sensitivity | -11.1 dBm |
| Media Type | Multi-Mode Fiber (MMF) |
| TX Wavelength | 850 nm |
| RX Wavelength | 850 nm |
| Minimum Optical Budget | 4.6 dB |
| Maximum Distance | 300m |
| Supported Data Rate | 1.0625-10.52 Gbps |
| Supported Applications |
|
| DDM/DOM | Support |
| Receiver Overload | -1 dBm |
| Dispersion | 110 ps/nm |
| Transmitter Type | VSCEL Laser |
| Receiver Type | PIN photodiode |
| Power | +3.3V single power supply |
| Chipset | MAXIM, MINDSPEED, SEMTECH |
| Compliance |
|
| Transceiver Type | SFP+ |
