Brand Name:
Finisar
Model Number:
FTLF8519P3BNL
Document:
| Model | FTLF8519P3BNL |
| Description | Finisar Optical Transceiver Module Dual LC MMF 850nm 1000BASE-SX 1.25G SFP 500m |
| Media Type | Multi-Mode Fiber (MMF) |
| TX/RX Wavelength | 850 nm |
| Wavelength Bandwidth | 20 nm (840-860 nm) |
| Data Rate | 100-2.67 Gbps |
| Maximum Distance | 500m |
| Transmitter Power | -9.5 dB to -3 dB |
| Receiver Sensitivity | -17 dBm |
| Receiver Overload | -3 dBm |
| Optical Budget | 7.5 dB |
| Dispersion | 110 ps/nm |
| Transmitter Type | VCSEL Laser |
| Receiver Type | PIN Photodiode |
| Power Supply | +3.3V |
| Temperature Range | Extended -20°C to 85°C |
| Connectors | Dual LC |
| Compliance | CE, Class 1 FDA, IEC60825-1, INF-8074i, RoHS, SFP MSA |
