Name: H801MCUD Huawei MCUD MA5600T Control Board 256 Gbit/s 24 x GE
Brand: Hangzhou Nanyin Trading Co., Ltd.
SKU: MCUD
Price: 70 USD
Availability: InStock

Home > Products > Huawei OLT Board >

H801MCUD Huawei MCUD MA5600T Control Board 256 Gbit/s 24 x GE

256Gbit Huawei MCUD

24 x GE Huawei MCUD

H801MCUD

Place of Origin:

China

Brand Name:

Huawei

Certification:

Model Number:

MCUD

Document:

huawei-h801mcud-datasheet.pdf

Chat Now

Request A Quote

Product Details

Condition:

Original New; In Stock

Demension:

442mm*268.7mm*88.1mm

Ac Power Supply:

100V To 240V

Uplink Interface:

4 *GE (Optical )+2*GE(Electronic)

Pon Board:

XGHD,GPSF

Application:

FTTH FTTB FTTX Network

Humidity:

5%~95% (non-condensing)

Maxports:

16 PON Ports

Securityfeatures:

Encryption, Authentication, ACL

Product Status:

Stock

Uplinkinterface:

10GE/40GE/100GE

Qos:

Supports Multiple QoS Policies

Support:

L2/L3 Features

Pon Capacity:

8-32Ports

Main Control Board:

SCUN

Type:

Optical Line Terminal

Highlight:

256Gbit Huawei MCUD

24 x GE Huawei MCUD

H801MCUD

Payment & Shipping Terms

Minimum Order Quantity

1pc

Price

$70

Packaging Details

Box

Delivery Time

3-5 working days

Payment Terms

T/T,Western Union,MoneyGram

Supply Ability

100 pcs

Huawei EA5801E-GP16 Optical Line Terminal with 16 GPON ports 10GE/GE upstream ports and RS-232 serial port for FTTH network construction

Chat Now

Huawei MA5603T OLT Optical Line Terminal with 6U 10GPON and 1.5Tbit/s Backplane Capacity

Chat Now

Huawei SmartAX MA5800-X2 (AC/ DC Supply) with 40G capacity Original New

Chat Now

Huawei SmartAX EA5801 OLT with 4 x G-PON and GPON Combo AC Power Supply Compact Design for Rapid Deployment

Chat Now

86-180-5715-6223

info@hi-network.com

Chat Now

Product Description

Huawei MCUD MA5600T Control Boards

Overview

The H801MCUD board is an integrated optical-copper mini control unit board that serves as the core for system control and service switching and aggregation, designed specifically for the MA5608T subrack.

Quick Specification

Model	H801MCUD
LAN Switch	24 x GE + 4 x 10GE
Switching Capacity	• 128 Gbit/s (active/standby mode) • 256 Gbit/s (load sharing mode)
Bandwidth per Slot	• 10 Gbit/s (active/standby mode) • 20 Gbit/s (load sharing mode)
MAC Address Table	32768
Access ONT	• Before V800R015C10 version: 2048 • V800R015C10 and later versions: 4096
Multicast User	4096

Product Features

H801MCUD Key Benefits:

Supports up to 256 Gbit/s switching capacity
Supports active/standby mode and load sharing mode, doubling processing performance
Supports ISSU (In-Service Software Upgrade), reducing upgrade interruption time
Supports Synchronization Ethernet

External Interfaces:

Management Interfaces:
- CONSOLE/ESC (RJ-45)
- CONSOLE: RS-232 serial port
- ESC: RS-485 monitoring serial port
- ETH (RJ-45): 10/100M Base-T maintenance network port
- AUX (RJ-45), Reserved
- ALARM IN/OUT (RJ-45): 7 alarm digital inputs and 1 alarm digital output
Communication Interfaces:
- GE0 to GE3 (4 x SFP GE ports): Used for upstream transmission or cascading

Comparison with Similar Models

Feature	H801MCUD	H801SCUH
LAN Switch	24 x GE + 4 x 10GE	48 x 10GE
Switching Capacity	• 128 Gbit/s (active/standby mode) • 256 Gbit/s (load sharing mode)	• 960 Gbit/s (active/standby mode) • 1920 Gbit/s (load sharing mode)
Bandwidth per Slot	• 10 Gbit/s (active/standby mode) • 20 Gbit/s (load sharing mode)	• 20 Gbit/s (active/standby mode) • 40 Gbit/s (load sharing mode)
MAC Address Table	32768	131072
Access ONT	• Before V800R015C10: 2048 • V800R015C10+: 4096	16384
