Name: Huawei MA5800 Main Control Board with 2-port 10GE/GE and 2-port GE Optical Uplink Port for 40Gbit/s Bandwidth
Brand: Hangzhou Nanyin Trading Co., Ltd.
SKU: MPSG
Price: 778 USD
Availability: InStock

Home > Products > Huawei OLT Board >

Huawei MA5800 Main Control Board with 2-port 10GE/GE and 2-port GE Optical Uplink Port for 40Gbit/s Bandwidth

2-port 10GE/GE Huawei MA5800 Main Control Board

2-port GE optical uplink port Huawei OLT Control Card

40Gbit/s bandwidth Huawei MPSG Main Control Board

Place of Origin:

China

Brand Name:

Huawei

Certification:

Model Number:

MPSG

Document:

huawei-h901mpsg-datasheet.pdf

Chat Now

Request A Quote

Product Details

Detail:

Huawei MA5800 Main Control Board Integrated With 2-port 10GE 2port GE Optical Uplink Port

Condition:

New; In Stock

Highlight:

2-port 10GE/GE Huawei MA5800 Main Control Board

2-port GE optical uplink port Huawei OLT Control Card

40Gbit/s bandwidth Huawei MPSG Main Control Board

Payment & Shipping Terms

Minimum Order Quantity

1pc

Price

$778

Packaging Details

Box

Delivery Time

3-5 working days

Payment Terms

T/T,Western Union,MoneyGram

Supply Ability

100 pcs

Huawei EA5801E-GP16 Optical Line Terminal with 16 GPON ports 10GE/GE upstream ports and RS-232 serial port for FTTH network construction

Chat Now

info@hi-network.com

Chat Now

Product Description

Huawei MPSG H901 H902 MA5800 X2 Main Control Board

Product Overview

Integrated Huawei MA5800 X2 main control board featuring 2-port 10GE/GE and 2-port GE optical uplink port connectivity for high-performance networking applications.

Technical Specifications

Feature	H901MPSA	H901MPSC	H901MPSG
Bandwidth per slot (load balancing mode)	40Gbit/s	80Gbit/s	40Gbit/s
Upstream or cascaded port	2×10GE/GE + 2×GE	4×10GE/GE	2×10GE/GE + 2×GE
Sync ETH clock	Yes	Yes	No
1588 ACR	No	No	No
1588v2 sync	Yes	Yes	No
ALM port (alarm digital parameters)	Yes	Yes	Yes
BITS/TOD port	Yes	Yes	Yes

Key Features

High-performance main control board for Huawei MA5800 X2 series
Multiple port configurations for flexible network deployment
Advanced synchronization capabilities (varies by model)
Comprehensive alarm and timing interface support
Robust bandwidth options for diverse application requirements
